TM024HDH47
TM024HDSP01
TM024HDSP01
TM024HDH47
TM024HDSP01
| Item | Specification |
|---|---|
| Outline Dimension(mm) | 42.72 x 60.26 x 2.25 |
| Active Area(mm) | 36.72 x 48.96 |
| Resolution(pixel) | 240 x 320 |
| Contrast Ratio | 350 |
| Viewing Angle(U/D/L/R) | 70 / 60 / 70 / 70 |
| Interface | CPU |
| Backlight Type | LED |
| Mass Production | MP |
| Brightness(cd/㎡) | 225 |
| With TP | No |
| Application | Mobile phone |
TM024HDSP01
| Item | Specification |
|---|---|
| Outline Dimension(mm) | 39.72 x 56.36 x 0.60 |
| Active Area(mm) | 36.72 x 48.96 |
| Resolution(pixel) | 240 x 320 |
| Contrast Ratio | 900 |
| Viewing Angle(U/D/L/R) | 85 / 85 / 85 / 85 |
| Interface | CPU |
| Backlight Type | LED |
| Mass Production | MP |
| Brightness(cd/㎡) | 300 |
| With TP | No |
| Application | Mobile phone |
