TM035KBH02
TM035KDH03
TM035WDH01
TM035KDH03
TM035WDH01
TM035KBH02
TM035KDH03
TM035WDH01
| Item | Specification |
|---|---|
| Outline Dimension(mm) | 76.90 x 63.90 x 4.00 |
| Active Area(mm) | 70.08 x 52.56 |
| Resolution(pixel) | 320 x 240 |
| Luminance(nits) | 350 |
| Contrast Ratio | 350 |
| Viewing Angle(U/D/L/R) | 40 / 60 / 60 / 60 |
| Interface | RGB/CCIR656/601 |
| Backlight Type | LED |
| Mass Production | MP |
| With TP | Yes |
TM035KDH03
| Item | Specification |
|---|---|
| Outline Dimension(mm) | 76.90 x 63.90 x 3.15 |
| Active Area(mm) | 70.08 x 52.56 |
| Resolution(pixel) | 320 x 240 |
| Luminance(nits) | 300 |
| Contrast Ratio | 350 |
| Viewing Angle(U/D/L/R) | 40 / 60 / 60 / 60 |
| Interface | RGB/CCIR656/601 |
| Backlight Type | LED |
| Mass Production | MP |
| With TP | No |
TM035WDH01
| Item | Specification |
|---|---|
| Outline Dimension(mm) | 64.00 x 85.00 x 3.00 |
| Active Area(mm) | 53.28 x 71.04 |
| Resolution(pixel) | 480 x 640 |
| Luminance(nits) | 300 |
| Contrast Ratio | 500 |
| Viewing Angle(U/D/L/R) | 70 / 70 / 60 / 70 |
| Interface | RGB 18 bits+SPI |
| Backlight Type | LED |
| Mass Production | 2013Q2 |
| With TP | No |
