天马10.4寸屏
特点描述：TM104SBH01/TM104SDH01/TM104SDH03
资料下载
- 产品概述
- 参数规格表
- 行业应用
TM104SBH01
TM104SDH01
TM104SDH03
TM104SDH01
TM104SDH03
TM104SBH01
TM104SDH01
TM104SDH03
| Item | Specification |
|---|---|
| Outline Dimension(mm) | 236.00 x 176.90 x 5.60 |
| Active Area(mm) | 211.20 x 158.40 |
| Resolution(pixel) | 800 x 600 |
| Luminance(nits) | 400 |
| Contrast Ratio | 400 |
| Viewing Angle(U/D/L/R) | 60 / 70 / 70 / 70 |
| Interface | LVDS |
| Backlight Type | LED |
| Mass Production | MP |
| With TP | No |
TM104SDH01
| Item | Specification |
|---|---|
| Outline Dimension(mm) | 236.00 x 176.90 x 5.60 |
| Active Area(mm) | 211.20 x 158.40 |
| Resolution(pixel) | 800 x 600 |
| Luminance(nits) | 400 |
| Contrast Ratio | 400 |
| Viewing Angle(U/D/L/R) | 60 / 70 / 70 / 70 |
| Interface | LVDS |
| Backlight Type | LED |
| Mass Production | MP |
| With TP | No |
TM104SDH03
| Item | Specification |
|---|---|
| Outline Dimension(mm) | 243.00 x 179.40 x 8.50 |
| Active Area(mm) | 211.20 x 158.40 |
| Resolution(pixel) | 800 x 600 |
| Luminance(nits) | 350 |
| Contrast Ratio | 500 |
| Viewing Angle(U/D/L/R) | 60 / 70 / 70 / 70 |
| Interface | LVDS 8-bit/6-bit |
| Backlight Type | LED |
| Mass Production | 2013Q2 |
| With TP | No |
