Module parameter	Operation Voltage	5.0V
	Bus Timing	8080 bus
	Bus median	8-bit, 16-bit compatible parallel interface
Structural parameters	Outline（mm）	186.1×101.2×15MAX
Structural parameters	VA（mm）	154.08×86.58
TFT Parameters	Size (inch)	7
	Technology Type	a-si TFT
	Resolution	480(RGB) x 234
	Dot pitch	0.321（H)x0.370(V)
	Color depth	16 bits color
	Viewing Angle	12 o’clock
	BL	LED
	Luminance	200 cd/m2
	Contrast Ratio(Degree)	300
	NTSC	50
Temperature Parameter	Operation Voltage	-20℃ ~+70℃
Temperature Parameter	Storage Temperature	-30℃ ~+80℃
